3 doors plug-in
Pizza EN60x40 counter 3 doors
TZ17/1M-710
Pizza EN60x40 counter 3 doors
-2°+8°C
granite top h. 710 mm
Plug-in
-2°+8°C
granite top h. 710 mm
Plug-in
Features
- Standard equipment 12 slides EN60x40
- Control Electronic, display flush with the panel
- Doors 3 doors, self-closing, reversible with 105° stop
- Door gasket Magnetic, triple chamber and easily replaceable
- Insulation 60 mm thickness - CFC/HCFC free
- Exterior/interior finishing Exterior and interior AISI 304 stainless steel.
- Inner corners Rounded for easy cleaning and ensuring maximum hygiene
- Handle Stainless steel AISI 304, 2 mm thick
- Racks and slides Stainless steel AISI 304
- Top With top and splashback
- Feets AISI 304 stainless steel adjustable h 100/150 mm
Constructive Data
- Gross capacity 607 lt
- Temperature range -2°+8°C
- Refrigerant unit Plug-in
- Energetic class B
- Energy efficiency index 31
- Annual consumption 858 kW/h annum
- 24h consumption 2,351 kW/h/24h
- Climate class 5
- Cooling gas R290
- Defrost Hot gas
- Body height 710 mm
- Valve Supplied standard with solenoid
- Dimensions 2005×800×1040 mm
- Packing dimensions 2100×900×998 mm
- Gross weight 260 Kg
- Voltage 220-240 V - 50 Hz
- Total rate 250 W
- Absorbed Current 1,15 A
- Cooling capacity 406 W*
- * Evap. -10°C Cond. +55°C
Accessories
- Adjustable feet h 145/195 mm
- 6 Swivel and brake castors h 128 mm
- Frame fitted with telescopic EN60x40 slides
- EN60x40 Pizza container h 60 mm
- Aluminium coated backingan EN60x40 h 20 mm
- Pair of type L slides 605 mm
- Serial interface, RS485 cable
- Cosmo cable connection kit
- Cosmo wifi connection kit
- IP44 schuko socket with cover
- Removable plinth EN 3D h 100 mm
- Removable plinth EN 4D h 150 mm
Variants
- Drawers 1/2
- Drawers 1/3
- Drawers 1/3 + 2/3
- Lock with key for drawer 1/2
- Lock with key for drawer 1/3
- Lock with key for drawer 1/3 + 2/3
- Plug-in water unit
- Alimentazione frequenza 60Hz
- Other special voltage
Display case for ingredients 2005 mm
VP20/9N
Display case for ingredients 2005 mm
GN1/4 +2°+10°C
with glass
Plug-in
GN1/4 +2°+10°C
with glass
Plug-in
Features
- Control Electronic, display flush with the panel
- Insulation 30 mm thickness - CFC/HCFC free
- Exterior/interior finishing Exterior and interior AISI 304 stainless steel.
- Inner corners Rounded for easy cleaning and ensuring maximum hygiene
Constructive Data
- Gross capacity 63 lt
- Temperature range +2°+10°C
- Refrigerant unit Plug-in
- Cooling gas R290
- Valve Supplied standard with solenoid
- Dimensions 2005×320×485 mm
- Packing dimensions 2065×390×473 mm
- Gross weight 75 Kg
- Voltage 220-240 V - 50 Hz
- Total rate 250 W
- Absorbed Current 1,15 A
- Cooling capacity 406 W*
- * Evap. -10°C Cond. +55°C
Accessories
- 2005 display case pans kit, GN1/4
- Wall clamps, 2 pieces
- Kit of 4 stainless steel feets
- Cosmo cable connection kit
- Cosmo wifi connection kit
- Pan GN1/1 325x530x150 mm
- Lid for GN1/1 pan
- Pan GN1/2 325x265x150 mm
- Lid for GN1/2 pan
- Pan GN1/4 265x162x150 mm
- Lid for GN1/4 pan
- Pan GN1/6 176x162x150 mm
- Lid for GN1/6 pan
- Pan GN1/9 176x108x100 mm
- Lid for GN1/9 pan
- Brackets for pans 20 mm GN1/4
- Brackets for pans 25 mm GN1/4
- Brackets for pans 30 mm GN1/4
Variants
- Alimentazione frequenza 60Hz
- Other special voltage
Display case for ingredients 2005 mm
VP20/9NL
Display case for ingredients 2005 mm
GN1/3 +2°+10°C
with glass
Plug-in
GN1/3 +2°+10°C
with glass
Plug-in
Features
- Control Electronic, display flush with the panel
- Insulation 30 mm thickness - CFC/HCFC free
- Exterior/interior finishing Exterior and interior AISI 304 stainless steel.
- Inner corners Rounded for easy cleaning and ensuring maximum hygiene
Constructive Data
- Gross capacity 79 lt
- Temperature range +2°+10°C
- Refrigerant unit Plug-in
- Cooling gas R290
- Valve Supplied standard with solenoid
- Dimensions 2005×380×485 mm
- Packing dimensions 2065×450×473 mm
- Gross weight 80 Kg
- Voltage 220-240 V - 50 Hz
- Total rate 250 W
- Absorbed Current 1,15 A
- Cooling capacity 406 W*
- * Evap. -10°C Cond. +55°C
Accessories
- 2005 display case pans kit, GN1/3
- Wall clamps, 2 pieces
- Kit of 4 stainless steel feets
- Cosmo cable connection kit
- Cosmo wifi connection kit
- Pan GN1/2 325x265x150 mm
- Lid for GN1/2 pan
- Pan GN1/3 325x176x150 mm
- Lid for GN1/3 pan
- Pan GN1/6 176x162x150 mm
- Lid for GN1/6 pan
- Pan GN1/9 176x108x100 mm
- Lid for GN1/9 pan
- Pan GN2/8 325x132x150 mm
- Lid for GN2/8 pan
- Brackets for pans 20 mm GN1/3
- Brackets for pans 25 mm GN1/3
- Brackets for pans 30 mm GN1/3
Variants
- Alimentazione frequenza 60Hz
- Other special voltage
