2 doors plug-in
Retarder-prover Vision counter with 2 doors
TFA13/1MJ-660
Retarder-prover Vision counter with 2 doors
-6°+40°C RH 45÷95%
top with splashback h. 660 mm
-6°+40°C RH 45÷95%
top with splashback h. 660 mm
Features
- Functions Retarder prover, manual proving, continuous cycle, storage, chocolate, thawing, ice cream
- Standard equipment 14 slides EN60x40
- Control 7" touch screen display with USB port
- Doors 2 doors, self-closing, reversible with 105° stop
- Door gasket Magnetic, triple chamber and easily replaceable
- Insulation 60 mm thickness - CFC/HCFC free
- Exterior/interior finishing Exterior and interior AISI 304 stainless steel.
- Inner corners Rounded for easy cleaning and ensuring maximum hygiene
- Handle Stainless steel AISI 304, 2 mm thick
- Racks and slides Stainless steel AISI 304, quick release
- Top With top and splashback
- Feets AISI 304 stainless steel adjustable h 100/150 mm
Constructive Data
- Max capacity 14 trays EN60x40
- Gross capacity 357 lt
- Temperature range -6°+40°C
- Refrigerant unit Plug-in
- Cooling gas R290
- Defrost Hot gas
- Body height 660 mm
- Valve Supplied standard with solenoid
- Dimensions 1450×800×900 mm
- Packing dimensions 1545×900×998 mm
- Gross weight 164 Kg
- Voltage 220-240 V - 50 Hz
- Total rate 550 W
- Absorbed Current 2,5 A
- Cooling capacity 565 W*
- * Evap. -10°C Cond. +55°C
Accessories
- Purity C Quell ST 50 filter cartridge
- 4 Swivel and brake castors h 128 mm
- Aluminium coated backingan EN60x40 h 20 mm
- Stainless steel shelf EN60x40
- Plastic coated shelf EN60x40
- Pair of type L slides 402 mm EN
- Serial interface, RS485 cable
Variants
- RAL customisable colouring
- Plug-in water unit
- Alimentazione frequenza 60Hz
- Other special voltage
Retarder-prover Vision counter with 2 doors
TFP13/1MJ-660
Retarder-prover Vision counter with 2 doors
-6°+40°C RH 45÷95%
with top h. 660 mm
-6°+40°C RH 45÷95%
with top h. 660 mm
Features
- Functions Retarder prover, manual proving, continuous cycle, storage, chocolate, thawing, ice cream
- Standard equipment 14 slides EN60x40
- Control 7" touch screen display with USB port
- Doors 2 doors, self-closing, reversible with 105° stop
- Door gasket Magnetic, triple chamber and easily replaceable
- Insulation 60 mm thickness - CFC/HCFC free
- Exterior/interior finishing Exterior and interior AISI 304 stainless steel.
- Inner corners Rounded for easy cleaning and ensuring maximum hygiene
- Handle Stainless steel AISI 304, 2 mm thick
- Racks and slides Stainless steel AISI 304, quick release
- Top With top
- Feets AISI 304 stainless steel adjustable h 100/150 mm
Constructive Data
- Max capacity 14 trays EN60x40
- Gross capacity 357 lt
- Temperature range -6°+40°C
- Refrigerant unit Plug-in
- Cooling gas R290
- Defrost Hot gas
- Body height 660 mm
- Valve Supplied standard with solenoid
- Dimensions 1450×800×800 mm
- Packing dimensions 1545×900×998 mm
- Gross weight 159 Kg
- Voltage 220-240 V - 50 Hz
- Total rate 550 W
- Absorbed Current 2,5 A
- Cooling capacity 565 W*
- * Evap. -10°C Cond. +55°C
Accessories
- Purity C Quell ST 50 filter cartridge
- 4 Swivel and brake castors h 128 mm
- Aluminium coated backingan EN60x40 h 20 mm
- Stainless steel shelf EN60x40
- Plastic coated shelf EN60x40
- Pair of type L slides 402 mm EN
- Serial interface, RS485 cable
Variants
- RAL customisable colouring
- Plug-in water unit
- Alimentazione frequenza 60Hz
- Other special voltage
Retarder-prover Vision counter with 2 doors
TFS13/1MJ-660
Retarder-prover Vision counter with 2 doors
-6°+40°C RH 45÷95%
without top h. 660 mm
-6°+40°C RH 45÷95%
without top h. 660 mm
Features
- Functions Retarder prover, manual proving, continuous cycle, storage, chocolate, thawing, ice cream
- Standard equipment 14 slides EN60x40
- Control 7" touch screen display with USB port
- Doors 2 doors, self-closing, reversible with 105° stop
- Door gasket Magnetic, triple chamber and easily replaceable
- Insulation 60 mm thickness - CFC/HCFC free
- Exterior/interior finishing Exterior and interior AISI 304 stainless steel.
- Inner corners Rounded for easy cleaning and ensuring maximum hygiene
- Handle Stainless steel AISI 304, 2 mm thick
- Racks and slides Stainless steel AISI 304, quick release
- Top Without top
- Feets AISI 304 stainless steel adjustable h 100/150 mm
Constructive Data
- Max capacity 14 trays EN60x40
- Gross capacity 357 lt
- Temperature range -6°+40°C
- Refrigerant unit Plug-in
- Cooling gas R290
- Defrost Hot gas
- Body height 660 mm
- Valve Supplied standard with solenoid
- Dimensions 1450×780×760 mm
- Packing dimensions 1545×900×998 mm
- Gross weight 124 Kg
- Voltage 220-240 V - 50 Hz
- Total rate 550 W
- Absorbed Current 2,5 A
- Cooling capacity 565 W*
- * Evap. -10°C Cond. +55°C
Accessories
- Purity C Quell ST 50 filter cartridge
- 4 Swivel and brake castors h 128 mm
- Aluminium coated backingan EN60x40 h 20 mm
- Stainless steel shelf EN60x40
- Plastic coated shelf EN60x40
- Pair of type L slides 402 mm EN
- Serial interface, RS485 cable
Variants
- RAL customisable colouring
- Plug-in water unit
- Alimentazione frequenza 60Hz
- Other special voltage
Retarder-prover Vision counter with 2 doors
TFA13/1MJ-710
Retarder-prover Vision counter with 2 doors
-6°+40°C RH 45÷95%
top with splashback h. 710 mm
-6°+40°C RH 45÷95%
top with splashback h. 710 mm
Features
- Functions Retarder prover, manual proving, continuous cycle, storage, chocolate, thawing, ice cream
- Standard equipment 14 slides EN60x40
- Control 7" touch screen display with USB port
- Doors 2 doors, self-closing, reversible with 105° stop
- Door gasket Magnetic, triple chamber and easily replaceable
- Insulation 60 mm thickness - CFC/HCFC free
- Exterior/interior finishing Exterior and interior AISI 304 stainless steel.
- Inner corners Rounded for easy cleaning and ensuring maximum hygiene
- Handle Stainless steel AISI 304, 2 mm thick
- Racks and slides Stainless steel AISI 304, quick release
- Top With top and splashback
- Feets AISI 304 stainless steel adjustable h 100/150 mm
Constructive Data
- Max capacity 14 trays EN60x40
- Gross capacity 389 lt
- Temperature range -6°+40°C
- Refrigerant unit Plug-in
- Cooling gas R290
- Defrost Hot gas
- Body height 710 mm
- Valve Supplied standard with solenoid
- Dimensions 1450×800×950 mm
- Packing dimensions 1545×900×998 mm
- Gross weight 170 Kg
- Voltage 220-240 V - 50 Hz
- Total rate 550 W
- Absorbed Current 2,5 A
- Cooling capacity 565 W*
- * Evap. -10°C Cond. +55°C
Accessories
- Purity C Quell ST 50 filter cartridge
- 4 Swivel and brake castors h 128 mm
- Aluminium coated backingan EN60x40 h 20 mm
- Stainless steel shelf EN60x40
- Plastic coated shelf EN60x40
- Pair of type L slides 402 mm EN
- Serial interface, RS485 cable
Variants
- RAL customisable colouring
- Plug-in water unit
- Alimentazione frequenza 60Hz
- Other special voltage
Retarder-prover Vision counter with 2 doors
TFP13/1MJ-710
Retarder-prover Vision counter with 2 doors
-6°+40°C RH 45÷95%
with top h. 710 mm
-6°+40°C RH 45÷95%
with top h. 710 mm
Features
- Functions Retarder prover, manual proving, continuous cycle, storage, chocolate, thawing, ice cream
- Standard equipment 14 slides EN60x40
- Control 7" touch screen display with USB port
- Doors 2 doors, self-closing, reversible with 105° stop
- Door gasket Magnetic, triple chamber and easily replaceable
- Insulation 60 mm thickness - CFC/HCFC free
- Exterior/interior finishing Exterior and interior AISI 304 stainless steel.
- Inner corners Rounded for easy cleaning and ensuring maximum hygiene
- Handle Stainless steel AISI 304, 2 mm thick
- Racks and slides Stainless steel AISI 304, quick release
- Top With top
- Feets AISI 304 stainless steel adjustable h 100/150 mm
Constructive Data
- Max capacity 14 trays EN60x40
- Gross capacity 389 lt
- Temperature range -6°+40°C
- Refrigerant unit Plug-in
- Cooling gas R290
- Defrost Hot gas
- Body height 710 mm
- Valve Supplied standard with solenoid
- Dimensions 1450×800×850 mm
- Packing dimensions 1545×900×998 mm
- Gross weight 165 Kg
- Voltage 220-240 V - 50 Hz
- Total rate 550 W
- Absorbed Current 2,5 A
- Cooling capacity 565 W*
- * Evap. -10°C Cond. +55°C
Accessories
- Purity C Quell ST 50 filter cartridge
- 4 Swivel and brake castors h 128 mm
- Aluminium coated backingan EN60x40 h 20 mm
- Stainless steel shelf EN60x40
- Plastic coated shelf EN60x40
- Pair of type L slides 402 mm EN
- Serial interface, RS485 cable
Variants
- RAL customisable colouring
- Plug-in water unit
- Alimentazione frequenza 60Hz
- Other special voltage
Retarder-prover Vision counter with 2 doors
TFS13/1MJ-710
Retarder-prover Vision counter with 2 doors
-6°+40°C RH 45÷95%
without top h. 710 mm
-6°+40°C RH 45÷95%
without top h. 710 mm
Features
- Functions Retarder prover, manual proving, continuous cycle, storage, chocolate, thawing, ice cream
- Standard equipment 14 slides EN60x40
- Control 7" touch screen display with USB port
- Doors 2 doors, self-closing, reversible with 105° stop
- Door gasket Magnetic, triple chamber and easily replaceable
- Insulation 60 mm thickness - CFC/HCFC free
- Exterior/interior finishing Exterior and interior AISI 304 stainless steel.
- Inner corners Rounded for easy cleaning and ensuring maximum hygiene
- Handle Stainless steel AISI 304, 2 mm thick
- Racks and slides Stainless steel AISI 304, quick release
- Top Without top
- Feets AISI 304 stainless steel adjustable h 100/150 mm
Constructive Data
- Max capacity 14 trays EN60x40
- Gross capacity 389 lt
- Temperature range -6°+40°C
- Refrigerant unit Plug-in
- Cooling gas R290
- Defrost Hot gas
- Body height 710 mm
- Valve Supplied standard with solenoid
- Dimensions 1450×780×810 mm
- Packing dimensions 1545×900×998 mm
- Gross weight 130 Kg
- Voltage 220-240 V - 50 Hz
- Total rate 550 W
- Absorbed Current 2,5 A
- Cooling capacity 565 W*
- * Evap. -10°C Cond. +55°C
Accessories
- Purity C Quell ST 50 filter cartridge
- 4 Swivel and brake castors h 128 mm
- Aluminium coated backingan EN60x40 h 20 mm
- Stainless steel shelf EN60x40
- Plastic coated shelf EN60x40
- Pair of type L slides 402 mm EN
- Serial interface, RS485 cable
Variants
- RAL customisable colouring
- Plug-in water unit
- Alimentazione frequenza 60Hz
- Other special voltage
Retarder-prover Vision counter with 2 doors
TFA13/1MJ-760
Retarder-prover Vision counter with 2 doors
-6°+40°C RH 45÷95%
top with splashback h. 760 mm
-6°+40°C RH 45÷95%
top with splashback h. 760 mm
Features
- Functions Retarder prover, manual proving, continuous cycle, storage, chocolate, thawing, ice cream
- Standard equipment 14 slides EN60x40
- Control 7" touch screen display with USB port
- Doors 2 doors, self-closing, reversible with 105° stop
- Door gasket Magnetic, triple chamber and easily replaceable
- Insulation 60 mm thickness - CFC/HCFC free
- Exterior/interior finishing Exterior and interior AISI 304 stainless steel.
- Inner corners Rounded for easy cleaning and ensuring maximum hygiene
- Handle Stainless steel AISI 304, 2 mm thick
- Racks and slides Stainless steel AISI 304, quick release
- Top With top and splashback
- Feets AISI 304 stainless steel adjustable h 100/150 mm
Constructive Data
- Max capacity 14 trays EN60x40
- Gross capacity 421 lt
- Temperature range -6°+40°C
- Refrigerant unit Plug-in
- Cooling gas R290
- Defrost Hot gas
- Body height 760 mm
- Valve Supplied standard with solenoid
- Dimensions 1450×800×1000 mm
- Packing dimensions 1545×900×998 mm
- Gross weight 176 Kg
- Voltage 220-240 V - 50 Hz
- Total rate 550 W
- Absorbed Current 2,5 A
- Cooling capacity 565 W*
- * Evap. -10°C Cond. +55°C
Accessories
- Purity C Quell ST 50 filter cartridge
- 4 Swivel and brake castors h 128 mm
- Aluminium coated backingan EN60x40 h 20 mm
- Stainless steel shelf EN60x40
- Plastic coated shelf EN60x40
- Pair of type L slides 402 mm EN
- Serial interface, RS485 cable
Variants
- RAL customisable colouring
- Plug-in water unit
- Alimentazione frequenza 60Hz
- Other special voltage
Retarder-prover Vision counter with 2 doors
TFP13/1MJ-760
Retarder-prover Vision counter with 2 doors
-6°+40°C RH 45÷95%
with top h. 760 mm
-6°+40°C RH 45÷95%
with top h. 760 mm
Features
- Functions Retarder prover, manual proving, continuous cycle, storage, chocolate, thawing, ice cream
- Standard equipment 14 slides EN60x40
- Control 7" touch screen display with USB port
- Doors 2 doors, self-closing, reversible with 105° stop
- Door gasket Magnetic, triple chamber and easily replaceable
- Insulation 60 mm thickness - CFC/HCFC free
- Exterior/interior finishing Exterior and interior AISI 304 stainless steel.
- Inner corners Rounded for easy cleaning and ensuring maximum hygiene
- Handle Stainless steel AISI 304, 2 mm thick
- Racks and slides Stainless steel AISI 304, quick release
- Top With top
- Feets AISI 304 stainless steel adjustable h 100/150 mm
Constructive Data
- Max capacity 14 trays EN60x40
- Gross capacity 421 lt
- Temperature range -6°+40°C
- Refrigerant unit Plug-in
- Cooling gas R290
- Defrost Hot gas
- Body height 760 mm
- Valve Supplied standard with solenoid
- Dimensions 1450×800×900 mm
- Packing dimensions 1545×900×998 mm
- Gross weight 171 Kg
- Voltage 220-240 V - 50 Hz
- Total rate 550 W
- Absorbed Current 2,5 A
- Cooling capacity 565 W*
- * Evap. -10°C Cond. +55°C
Accessories
- Purity C Quell ST 50 filter cartridge
- 4 Swivel and brake castors h 128 mm
- Aluminium coated backingan EN60x40 h 20 mm
- Stainless steel shelf EN60x40
- Plastic coated shelf EN60x40
- Pair of type L slides 402 mm EN
- Serial interface, RS485 cable
Variants
- RAL customisable colouring
- Plug-in water unit
- Alimentazione frequenza 60Hz
- Other special voltage
Retarder-prover Vision counter with 2 doors
TFS13/1MJ-760
Retarder-prover Vision counter with 2 doors
-6°+40°C RH 45÷95%
without top h. 760 mm
-6°+40°C RH 45÷95%
without top h. 760 mm
Features
- Functions Retarder prover, manual proving, continuous cycle, storage, chocolate, thawing, ice cream
- Standard equipment 14 slides EN60x40
- Control 7" touch screen display with USB port
- Doors 2 doors, self-closing, reversible with 105° stop
- Door gasket Magnetic, triple chamber and easily replaceable
- Insulation 60 mm thickness - CFC/HCFC free
- Exterior/interior finishing Exterior and interior AISI 304 stainless steel.
- Inner corners Rounded for easy cleaning and ensuring maximum hygiene
- Handle Stainless steel AISI 304, 2 mm thick
- Racks and slides Stainless steel AISI 304, quick release
- Top Without top
- Feets AISI 304 stainless steel adjustable h 100/150 mm
Constructive Data
- Max capacity 14 trays EN60x40
- Gross capacity 421 lt
- Temperature range -6°+40°C
- Refrigerant unit Plug-in
- Cooling gas R290
- Defrost Hot gas
- Body height 760 mm
- Valve Supplied standard with solenoid
- Dimensions 1450×780×860 mm
- Packing dimensions 1545×900×998 mm
- Gross weight 136 Kg
- Voltage 220-240 V - 50 Hz
- Total rate 550 W
- Absorbed Current 2,5 A
- Cooling capacity 565 W*
- * Evap. -10°C Cond. +55°C
Accessories
- Purity C Quell ST 50 filter cartridge
- 4 Swivel and brake castors h 128 mm
- Aluminium coated backingan EN60x40 h 20 mm
- Stainless steel shelf EN60x40
- Plastic coated shelf EN60x40
- Pair of type L slides 402 mm EN
- Serial interface, RS485 cable
Variants
- RAL customisable colouring
- Plug-in water unit
- Alimentazione frequenza 60Hz
- Other special voltage
